1. Introduction
For many years the construction industry has been trending towards inclusivity and higher standards of accessible design, resulting in clear guidelines to accommodate occupants with disabilities, in particular wheelchair users. However, limited guidance is given on how these occupants may evacuate a building in the event of fire.
Historically, evacuation of occupants is premised exclusively around the use of staircases, irrespective of building use or height, whereas the use of lifts/elevators during a fire event is prohibited or discouraged. This approach is not suitable for occupants with mobility impairments.
In UK, the New London Plan was released in March 2021 addressing these issues and advocating for all occupants to be able to evacuate independently and with dignity. This prompted AESG to undertake a comprehensive review of international requirements related to the evacuation of mobility impaired occupants in order to assess the different approaches and ultimately try to develop an overarching best practice approach.
2. Review of International Accessibility Requirements
Section 2 explores the current practices through a review of the following international design codes:
This paper focuses on residential apartment building, since other occupancies (such as retail, business, entertainment) are more likely to have a management team tasked with preparing personal emergency evacuation plans (PEEPs) for staff and visitors, which may compensate for a lack of built-in provisions. Moreover, while it is understood that there are a number of different disabilities that need to be considered and addressed, such as vision or hearing impairments, this paper focuses primarily on provisions for occupants with mobility impairments.
2.1. British Standard BS 9991
BS 9991 addresses the evacuation of disabled occupants in Chapter 54. While guidance is given on the use of horizontal evacuation and lifts and the need for ramps and handrails, Chapter 54 puts the emphasis on the operator to assess the needs of disabled occupants and develop evacuation plans, stating that ‘providing an accessible means of escape should be an integral part of fire safety management’. The lack of built-in provisions such as areas of refuge puts wheelchair occupants at a disadvantage and exposes them to a higher level of risk, due to their inability to use stairs.
Residential buildings in the UK are typically designed without a stair lobby or lift lobby, meaning that in the event of a fire scenario, wheelchair occupants need to find refuge in the common corridor or within the staircase until help arrives. The concern with this approach is that in the event of a severe fire scenario, visibility in the corridor can be very low, whereas temperatures and toxicity levels may be high. As for the staircases, these are rarely sized to accommodate a wheelchair refuge point, because this is not mandated by the code. Moreover, staircases in the UK tend to not be pressurised, meaning that smoke from the corridor could enter the staircase. It is noted that a new version of BS 9991 is currently under development and is expected to introduce staircase pressurisation requirements in high-rise apartment buildings with single stairs, or the need for at least two exit stairs.
Some of the concerns described above were addressed with the publication of the New London Plan in March 2021.
2.1.1. New London Plan 2021
Policy D5 of the New London Plan states that evacuation lifts, at least one per core, shall be provided in order to obtain planning approval. The intent is to allow all building users to be able to evacuate with dignity and as independently as possible. Emergency carry down devices are no longer considered to be appropriate. Lastly, where once the use of firefighting lifts for evacuation purposes was deemed acceptable, Policy D5 states that ‘evacuation lifts should not be misinterpreted as firefighting lifts’ and that ‘applicants must not make the provision for the installation of a firefighting lift where an evacuation lift is required by London Plan Policy D5(B5)’.
Below are the key design considerations for evacuation lifts:
In summary, the New London Plan has introduced measures that facilitate the safe evacuation of all occupants, thanks to the requirement for evacuation lifts and refuge points.
2.2. NFPA 101
In comparison to BS 9991, NFPA 101 is a more prescriptive document which leaves little room for interpretation. Requirements for areas of refuge are addressed in Section 7.2.12. Here it is stated that an area of refuge used as part of a required accessible means of egress shall be provided at each elevator landing and shall be fitted with a two-way communication system for communication between the elevator landing and the fire command center or a central control point approved by the authority having jurisdiction. Moreover, it states that each area of refuge shall be sized to accommodate one wheelchair space of 30 in. × 48 in. (760 mm × 1220 mm) for every 200 occupants. However, not all building types have to comply with these requirements. For example, in residential apartment buildings (Chapter 30) the provision of areas of refuge is ‘permitted’, but not required.
Additionally, Section 7.2.13 states that elevators shall be permitted to be used as a second means of egress from a tower, provided all of the following criteria are met:
These prerequisites restrict the use of the elevators for evacuation to a limited number of scenarios. In fact, the use of elevators for evacuation has generally been discouraged as a result of incidents involving the use of elevators during fire scenarios. The issue consisted in elevators stopping at fire floors and the elevator doors not being able to close, due to too many people trying to evacuate, resulting in occupants becoming trapped. The rejection of evacuation elevators was universal for a long time, but attitudes started to change following the 9/11 investigation. The benefits of elevator evacuation are now outlined in the 20th Edition of the NFPA Fire Protection Handbook, which is referenced in NFPA 101.
In summary, NFPA 101 does not require refuge areas in residential apartments, nor the use of evacuation elevators, meaning that the evacuation of mobility impaired occupants relies on the building’s facility management team. To this point, NFPA has published a document titled Emergency Evacuation Planning Guide for People with Disabilities, which outlines how to develop suitable evacuation plans for occupants depending on the type of impairment.
2.3. UAE Fire & Life Safety Code
Chapter 3 of the UAE Fire & Life Safety Code covers the general requirements for means of egress, whereas Chapter 13 talks specifically about accessibility requirements, with the intent of ensuring that people with determination can ‘manoeuvre, evacuate and find refuge as naturally as everyone’. This chapter sets out the requirements for ensuring that access and egress routes, such as doors, corridors, elevators, stairs, etc., are suitable for people with physical disability or mobility impairments. Additionally, it outlines the minimum allowable number of accessible parking bays and accessible units within buildings.
On the other hand, the evacuation procedures for mobility impaired occupants are not presented in a prescriptive manner, leaving it up to the interpretation of the designer to determine where features such as refuge areas and evacuation elevators should be provided. For example, Chapter 3 Section 3.9 talks about the use of elevators for evacuation purposes, but it is not clear when and where they should be provided, if ever. Below are some of the prerequisites for elevator evacuation:
The UAE Fire & Life Safety Code does not emphasize the need for independent evacuation and instead relies on able-bodied people to assist the evacuation of less able occupants through the use of stair descent devices and even elevator evacuation. In fact, Chapter 13 Section 5.2 states that ‘where mobility impaired people cannot use the accessible routes and elevators are not available for evacuation’, they can receive ‘assistance from first responders, Civil Defence personnel, fellow people, neighbours, colleagues, depending on the type of occupancy’.
2.4. Saudi Building Code, SBC 201
The Saudi Building Code (SBC 201), which is largely based on the International Building Code (IBC), has two chapters that outline accessibility requirements. Chapter 11, which is dedicated entirely to the subject of accessibility, covers the general aspects of access and day-to-day livability of a building, whereas Chapter 10 focuses on addressing the needs of occupants during a fire scenario or other events requiring evacuation of the building.
SBC is supplemented by the ‘Universal Accessibility Built Environment Guidelines for the Kingdom of Saudi Arabia’. This document is primarily intended to ensure that new buildings are inclusive towards occupants with disabilities by setting out accessibility requirements for common circulation areas and by defining minimum quotas for accessible rooms and parking.
SBC presents accessibility requirements in a prescriptive manner, setting out clear requirements for areas of refuge, two-way communication systems and evacuation elevators, among other requirements. However, numerous exceptions are made for buildings fitted throughout with an automatic sprinkler system and residential buildings. For example, Section 1009.2.1 states that ‘in buildings where an accessible floor is four or more stories above a level of exit discharge, not less than one required accessible means of egress shall be an elevator’. However, it also states that the evacuation elevator is not required in buildings equipped with an automatic sprinkler system. Another example is Section 1009.3, which states that ‘areas of refuge are not required in buildings equipped throughout with an automatic sprinkler system’. It is the opinion of the writer that the provision of active suppression systems such as sprinklers, while usually reliable and effective, should not replace built-in provisions.
In the context of residential apartments specifically, Section 1009.3 states that ‘areas of refuge are not required at stairways in Group R-2 occupancies’.
2.5. Singapore Code of Practice for Fire Precautions in Buildings
Requirements for persons with disabilities (PWDs) are covered in Chapter 2.4 of the Singapore Fire Code. The Singapore Fire Code is accompanied by the Code on Accessibility in the Built Environment (2018), which is a comprehensive guide to ensuring that all aspects of a building are accessible for people with disabilities, as well as older persons.
The requirements of the Singapore Fire Code are prescriptive, but residential buildings (Purpose Group I and Purpose Group II buildings) are exempt from these requirements. In fact, residential buildings are exempt from needing PWD holding points (refuge points), as well as evacuation lifts.
Super high-rise residential buildings are required to have refuge floors at intervals of no more than 20 storeys. However, this requirement is not specific to PWDs, and while it certainly benefits young children or older persons who may not be able to evacuate the building in its entirety, it does not benefit occupants with severe mobility impairments such as wheelchair occupants.
2.6. Summary
Among the codes reviewed, it is evident that the evacuation of mobility-impaired occupants relies heavily on external assistance from the building management team or firefighters. Only in UK with the introduction of the New London Plan, we are seeing compulsory measures being introduced in residential buildings intended to support the independent evacuation of mobility-impaired occupants. Findings from the review are presented and summarised inTable 1.
The next chapter looks at the challenges that wheelchair occupants may face in the event of a fire scenario and presents some ideas on how to mitigate these challenges.
Code / Standard | Elevator evacuation | Area of refuge | Emergency voice alarm | Two-way communication | Personal emergency evacuation plan (PEEP) |
---|---|---|---|---|---|
London Plan 2021 | Required in all developments where lifts are installed (Policy D5) | Required in conjunction with lift evacuation (Policy D5) | Not specified | Required in refuge points | Not specified |
BS 9991 | Required only in specialised housing (Section 8.4) | Required only in specialised housing (Section 8.3) | Not specified | Required in refuge points, where provided | Personal emergency evacuation plans should be provided for people with mobility impairments (Annex E, E.2) |
NFPA 101 | Evacuation-elevators are permitted, but not required (Section 7.2.13) | Areas of refuge are permitted, but not required (Section 30.2.2.12.1) | Required in residential buildings higher than 23m (Section 11.8.4.1) | Not required | Not required |
UAE Fire & Life Safety Code | Not mandated by Civil Defence (Section 3.9) | Not mandated by Civil Defence (Section 3.8) | Required in all buildings higher than 23m (Table 8.13) | Required in areas of refuge in buildings higher than 23m, as well as in elevators used for evacuation | Required (Chapter 15, Section 5) |
SBC 201 | Not required if sprinklers are provided (Section 1009.2.1) | Areas of refuge are not required in Group R-2 occupancies (Section 1009.3) | Required in buildings higher than 23m (Section 907.2.13) | Required in refuge points, where provided (Section 1009.6.5) Required in elevator lobbies in conjunction with evacuation elevators, where provided. (Section 3008.6.5) | General emergency evacuation plan shall be provided in conjunction with evacuation elevators (Section 3008.1.2) |
Singapore Fire Code | Residential buildings are exempt from needing evacuation lifts (Chapter 2.4) | Residential buildings are exempt from needing PWD holding points (Chapter 2.4) | Shall be provided in conjunction with evacuation lifts. (Section 6.6.5) | Not required in residential buildings (Section 8.2.1) | Not specified |
3. Assessment of Conditions within Refuge Areas
Section 2 of this paper provides an overview of the accessibility requirements in residential apartment buildings, revealing that there is a lack of prescriptive guidance in terms of evacuating occupants with disabilities. One of the main concerns is the lack of stricter requirements in relation to areas of refuge. This raises the question of where wheelchair occupants should find refuge during an evacuation. Section 3 aims to answer this question and provide recommendations on how to mitigate the challenges they face. These recommendations are based on an in-house computational fluid dynamics (CFD) study which evaluates three areas of refuge to determine which are more favourable. The three scenarios considered are:
The findings of the CFD analysis are summarised below:
It is noted that the results presented herein are not absolute and are only relevant to this comparative case study. In fact, the study has demonstrated that the results vary greatly depending on the building’s geometry (ceiling height, corridor width/length, opening dimensions, etc) or the modeller’s assumptions, in particular regarding door opening times and fan ramp up times. While the study does provide some indication of which corridor arrangements and ventilation systems are more likely to perform best at maintaining tenable conditions, the results highlight that there is not a single overarching approach for all scenarios and that undertaking modelling is highly important.
4. Conclusion
This paper has been written with the intent of understanding typical egress provisions for mobility-impaired occupants in residential buildings and ultimately make recommendations on best practices. The international codes reviewed for this paper are:
Given current building codes and regulations, the following is the authors opinion on general good practice for multi-storey residential apartments to ensure that all occupants are given the capability of escaping independently without outside support:
